Allstate 6256 Ch= 528.55041; Sears, Roebuck & Co. (ID = 613662) Car Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1959 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 2N544 2N411 2N409 2N409 SYL1396 2N408 2N408 2N307A
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 12; 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Allstate 6256 Ch= 528.55041 - Sears, Roebuck & Co.; Chicago
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Notes The Sears, Roebuck & Co Model Allstate 6256 is an Battery operated Automobile-Portable Transitorized AM Receiver.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 11-59, Set 462, Folder 4)

Model page created by Egon Penker. See "Data change" for further contributors.
