• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1941

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 57264

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6J7G 6J7G 6Y7G 6L6G 80

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm

• from Radiomuseum.org
• Model: Silvertone 8960 Ch= 138.140 [138.14] - Sears, Roebuck & Co.; Chicago

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 13 = 1942 and before

• Literature/Schematics (1)
• Riders 13-110
