Loose Coupler

Loose Coupler ; Sears, Roebuck & Co. (ID = 1186612) mod-pre26 Loose Coupler ; Sears, Roebuck & Co. (ID = 1186572) mod-pre26
Loose Coupler ; Sears, Roebuck & Co. (ID = 1040788) mod-pre26 Loose Coupler ; Sears, Roebuck & Co. (ID = 1040789) mod-pre26
Loose Coupler ; Sears, Roebuck & Co. (ID = 1040790) mod-pre26 Loose Coupler ; Sears, Roebuck & Co. (ID = 1040791) mod-pre26
Loose Coupler ; Sears, Roebuck & Co. (ID = 1040792) mod-pre26 Loose Coupler ; Sears, Roebuck & Co. (ID = 1040793) mod-pre26
Loose Coupler ; Sears, Roebuck & Co. (ID = 1040794) mod-pre26 Loose Coupler ; Sears, Roebuck & Co. (ID = 1040795) mod-pre26
Use red slider bar for more.
Loose Coupler ; Sears, Roebuck & Co. (ID = 1186612) mod-pre26
Sears, Roebuck & Co.: Loose Coupler [mod-pre26] ID = 1186612 933x461
Select picture or schematic to display from thumbnails on the right and click for download.
For model Loose Coupler, Sears, Roebuck & Co.; Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1916 ?? Category: Radio module pre 1926 (not a part, not a key)
Main principle RF-Circuit or wave trap (separate, can also be an antenna with amp.)
Wave bands Broadcast and LongWave in ONE range.
Details
Power type and voltage No Power needed
Loudspeaker
Power out
from Radiomuseum.org Model: Loose Coupler - Sears, Roebuck & Co.; Chicago
Material Various materials
Dimensions (WHD) 18 x 6.5 x 6 inch / 457 x 165 x 152 mm
Notes Identical to Arlington Signal by W.M. Duck (see catalog).
External source of data Konrad Birkner;

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
