Silvertone 102GY Ch= 528.50340 or CH= 528.50342

Sears, Roebuck & Co.; Chicago (IL)

  • Year
  • 1959 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 147901
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 14
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • from Radiomuseum.org
  • Model: Silvertone 102GY Ch= 528.50340 or CH= 528.50342 - Sears, Roebuck & Co.; Chicago
  • Notes
  • Channel 2 thru 13 VHF, 14 thru 83 UHF. Sams photofact set 486 folder 2 date 5-60 features the Silvertone models PC-100, PC-101, PC-102BE, PC-102GY, PC103, PC110, PC120 with chassis 456.50340 or 456.50342, the models PC-100-5, PC-101-5, PC-102-5BE, PC-102-5GY, PC-103-5, PC-110-5, PC-120-5 with chassis 456.50341 or 456.50343, the models 100, 101, 102BE, 102GY, 103, 110, 120 with chassis 528.50340 or 528.50342, the models 100-5, 101-5, 102-5BE, 102-5GY, 103-5, 110-5, 120-5 with chassis 528.50341 or 528.50343 as the same schematic.
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
