• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1936

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 87956

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• 6K7MG 6C5MG 6L7MG 6K7MG 6E5 6K7MG 6C5MG 6F5MG 6C5MG 6C5MG 6F6MG 6F6MG 5Z4MG

• Main principle
• Superhet with RF-stage; ZF/IF 385 kHz

• Tuned circuits
• 10 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Silvertone 1946 Ch= 388X [Late] - Sears, Roebuck & Co.; Chicago

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• Minor electrical changes between early and late model.

• Source of data
• Pre-War Consoles

• Circuit diagram reference
• Rider's Perpetual, Volume 7 = 1936 and before

• Literature/Schematics (1)
• Riders 7-12, 39, 40

• Author
• Model page created by a member from D. See "Data change" for further contributors.

• Other Models

• Here you find 5491 models, 3222 with images and 4200 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Sears, Roebuck & Co.; Chicago (IL)
