Silvertone 7 Transistor Medalist 2209 Order=57G 2209

Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 2415510) Radio Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 2415511) Radio
Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 2415513) Radio Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 1673940) Radio
Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 1673941) Radio Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 1673943) Radio
Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 2415512) Radio
Use red slider bar for more.
Silvertone 7 Transistor Medalist 2209 Order=57G 2209; Sears, Roebuck & Co. (ID = 2415510) Radio
Sears, Roebuck & Co.: Silvertone 7 Transistor Medalist 2209 Order=57G 2209 [Radio] ID = 2415510 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 7 Transistor Medalist 2209 Order=57G 2209, Sears, Roebuck & Co.; Chicago (IL):
ebay.com #333291901529 seller thriftchimp

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7:
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / AA: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm
Power out
from Radiomuseum.org Model: Silvertone 7 Transistor Medalist 2209 Order=57G 2209 - Sears, Roebuck & Co.; Chicago
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 6 x 3.5 x 1.5 inch / 152 x 89 x 38 mm
Notes
Model Cabinet (Silver-color grille)
2208 Black
2209 Ice Blue



Price in first year of sale 23.95 $
Literature/Schematics (2) Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1961, page 1234.)

Model page created by Noemi Erb. See "Data change" for further contributors.
