Silvertone 3027 Ch= 132.066 Order=57D 03027

Sears, Roebuck & Co.; Chicago (IL)

  • Year
  • 1953–1955
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 129970
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 105-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Silvertone 3027 Ch= 132.066 Order=57D 03027 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 275 x 130 x 145 mm / 10.8 x 5.1 x 5.7 inch
  • Notes
  • The Silvertone models 3025 (color Black), 3026 (color Ivory) and 3027 (color Red) from Sears Roebuck & Co. are AC operated AM superheterodyne receivers with electric clock.

  • Net weight (2.2 lb = 1 kg)
  • 2.1 kg / 4 lb 10 oz (4.626 lb)
  • Price in first year of sale
  • 29.95 $
  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
