Silvertone 4484 Ch= 100.150

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600229) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600230) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600231) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600232) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600233) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600234) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600235) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600236) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 630895) Radio

Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 630896) Radio
Use red slider bar for more.
Silvertone 4484 Ch= 100.150; Sears, Roebuck & Co. (ID = 1600229) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 9999 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A7 6D6 6H6G 6F5G 6B5 80
Main principle Superheterodyne (common); ZF/IF 262 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 50 to 60 cycles, 105 to 135 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 2.5 W (3.3 W max.)
from Radiomuseum.org Model: Silvertone 4484 Ch= 100.150 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Notes

This is a duplicate model.

Circuit diagram reference Rider's Perpetual, Volume 8 = 1937 and before
Literature/Schematics (1) Rider's Perpetual, Volume 8 = 1937 and before (Riders (Sears) 8-13, 14)
Literature/Schematics (2) Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 886 - 893)

Model page created by Dirk Taekels. See "Data change" for further contributors.
