Silvertone 6002 Ch= 100.195 early

Silvertone 6002 Ch= 100.195; Sears, Roebuck & Co. (ID = 647515) Radio

Silvertone 6002 Ch= 100.195; Sears, Roebuck & Co. (ID = 647517) Radio

Silvertone 6002 Ch= 100.195; Sears, Roebuck & Co. (ID = 647518) Radio

Silvertone 6002 Ch= 100.195; Sears, Roebuck & Co. (ID = 647520) Radio
Use red slider bar for more.
Silvertone 6002 Ch= 100.195; Sears, Roebuck & Co. (ID = 647515) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A8G 6K7 6Q7G 6K6G 6U5 5W4G
Main principle Superheterodyne (common); ZF/IF 465 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Silvertone 6002 Ch= 100.195 [early] - Sears, Roebuck & Co.; Chicago
Dimensions (WHD) 6 x 5 x 4 inch / 152 x 127 x 102 mm
Notes There is also a different model 6002 late with Chassis 132.818.
Circuit diagram reference Beitman Radio Diagrams Vol. 10, 1950
Literature/Schematics (1) Riders 10-37, 38, 39, 88

Model page created by Dirk Taekels. See "Data change" for further contributors.
