Silvertone 7142 Ch= 528.46300
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1958 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 321273
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 26
- Valves / Tubes
- 6BS8 6BR8 6DC6 6DC6 6DC6 6AH6 12BY7 6AN8 6U8 6U8 6T8 6AQ6 6C4 6BL7GT 6SN7GTA 6CB5 6AU4GTA or 6BL4 1X2B 3B2 or 3C2 6BK4 6AN8 6CL6 6BC7 6U8 12BH7A 21AXP22
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 7142 Ch= 528.46300 - Sears, Roebuck & Co.; Chicago
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Silvertone model 7142 is a 21" color TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 528.46300, VHF tuner 95-83 and picture tube 21AXP22.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 388 Folder 1 dated 2-58)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 400 Folder 5 Production changes bulletin 210 dated 5-58)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
