Silvertone 8151 Ch= 528.50155

Sears, Roebuck & Co.; Chicago (IL)

  • Year
  • 1958 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 322313
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 15
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Silvertone 8151 Ch= 528.50155 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Silvertone model 8151 is a 17" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis 528.50155, VHF-UHF tuner 95-131-0 and picture tube 17CFP4.



  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
