Silvertone Base Amplifier 200BXL Ch= 257.14313201

Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637234) Ampl/Mixer Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637235) Ampl/Mixer
Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637236) Ampl/Mixer Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637237) Ampl/Mixer
Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637238) Ampl/Mixer
Use red slider bar for more.
Silvertone Base Amplifier 200BXL Ch= 257.14313201; Sears, Roebuck & Co. (ID = 2637234) Ampl/Mixer
Sears, Roebuck & Co.: Silvertone Base Amplifier 200BXL Ch= 257.14313201 [Ampl/Mixer] ID = 2637234 600x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone Base Amplifier 200BXL Ch= 257.14313201, Sears, Roebuck & Co.; Chicago (IL):
Picture from reverb.com.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1970 ?? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Guitar Amplifier
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker 4 Loudspeakers
Power out 100 W (undistorted)
from Radiomuseum.org Model: Silvertone Base Amplifier 200BXL Ch= 257.14313201 - Sears, Roebuck & Co.; Chicago
Material Leather / canvas / plastic - over other material
Shape Console with any shape - in general
Notes

The is a later version of the 200BXL Ch= 1431.  The difference is that the earlier version mounts the power transistors on individual heat sinks whereas the later version uses the aluminum chassis for a heat sink.

Speakers are 2 x 12 inch and 2 x 15 inch diameter.

Model page created by David Erali. See "Data change" for further contributors.
