Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201

Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 1998025) Radio Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 1998026) Radio
Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003946) Radio Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003947) Radio
Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003948) Radio Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003949) Radio
Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003950) Radio Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003951) Radio
Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 2003952) Radio
Use red slider bar for more.
Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201; Sears, Roebuck & Co. (ID = 1998025) Radio
Sears, Roebuck & Co.: Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201 [Radio] ID = 1998025 1400x714
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201, Sears, Roebuck & Co.; Chicago (IL):
aus ebay, #252300118993, Verkäufer torpor69

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1968 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 6C9_Twin-Tetrode 12BE6 12BA6 12AU6 12AU7A 12AX7A 6BQ5 6BQ5 6CA4
Semiconductors (the count is only for transistors) 2:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Silvertone Tuner-Amplifier 7406 Ch= 528.63200 or 528.63201 - Sears, Roebuck & Co.; Chicago
Material Metal case
Shape Book-shelf unit.
Notes

The Sears Silvertone 7406 is an AC operated 9 tube, 2 transistor AM/FM Mpx stereo receiver.  Has internal loopstick antenna for AM and provisions for connecting an external AM and FM antenna.  Has push-pull audio output stage.  Uses 2 transistor circuit to drive the FM Stereo light. Has Qty(2) utility outlets mounted on the rear of the chassis that are controlled by the power switch of the receiver.

See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Warwick Electronics, Chicago Ill. (Sears Manufacturer Source Number Code 528).

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 994, supplementary folder dated 11/1968)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
