Slvertone 8100GR Ch= 528.50068

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538639) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538640) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538641) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538642) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538643) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538644) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538645) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538646) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538647) Television

Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538648) Television
Use red slider bar for more.
Slvertone 8100GR Ch= 528.50068; Sears, Roebuck & Co. (ID = 2538639) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1958 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 14: 3BC5 5AT8 3CB6 5AM8 6BH8 5U8 6BN8 5AQ5 6CM7 6CG7 12AV5GA 12AX4GTA 1B3GT 17CFP4
Main principle Superhet with RF-stage
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Slvertone 8100GR Ch= 528.50068 - Sears, Roebuck & Co.; Chicago
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes

Silvertone model 8100GR is a 17" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 528.50068, VHF tuner 95-130-0 and picture tube 17CFP4.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 389 Folder 3 dated 2-58)

Model page created by Dirk Taekels. See "Data change" for further contributors.
