• Country
• United States of America (USA)

• Manufacturer / Brand
• Sencore; Sioux Falls (SD)

• Year
• 1970 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 109578

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 12AU7A

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117; Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: Mighty Mite V TC-142 - Sencore; Sioux Falls SD

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 270 x 270 x 100 mm / 10.6 x 10.6 x 3.9 inch

• Notes
• Tube checker with 12 sockets.

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
