Ch= V72-02AA (72 Series)

Sentinel Radio Corp., Evanston, Illinois

  • Year
  • 1957 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 312676

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 17
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Ch= V72-02AA - Sentinel Radio Corp., Evanston
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Sentinel Chassis V72-02AA (72 Series) is a 21" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner 20E313-2 and picture tube 21ATP4.



  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
