65

65; Shelbern Industries (ID = 1841049) Radio 65; Shelbern Industries (ID = 1841050) Radio
65; Shelbern Industries (ID = 1841051) Radio 65; Shelbern Industries (ID = 1841052) Radio
65; Shelbern Industries (ID = 1841053) Radio 65; Shelbern Industries (ID = 1841054) Radio
Use red slider bar for more.
65; Shelbern Industries (ID = 1841049) Radio
Shelbern Industries: 65 [Radio] ID = 1841049 933x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model 65, Shelbern Industries (Canada) LTD. Montreal

Country:  Canada
Manufacturer / Brand:  Shelbern Industries (Canada) LTD. Montreal
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 12BE6 12BA6 12AV6 50C5
Semiconductors (the count is only for transistors) Selen
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.5 cm = 4.9 inch
Power out
from Radiomuseum.org Model: 65 - Shelbern Industries Canada LTD
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 275 x 150 x 110 mm / 10.8 x 5.9 x 4.3 inch
Notes

Rectificateur au sélénium.

Manufactured by Shelbern Industries (Canada), Ltd., Montreal,
under license of Canadian Radio Patents Ltd.

Net weight (2.2 lb = 1 kg) 3 lb 0 oz (3 lb) / 1.362 kg

Model page created by Jean Marcotte. See "Data change" for further contributors.



All listed radios etc. from Shelbern Industries (Canada) LTD. Montreal
Here you find 4 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
