• Country
• United States of America (USA)

• Manufacturer / Brand
• Sherwood, Chicago

• Year
• 2001

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 287779

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 100 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Audio Video Receiver RV-4060R - Sherwood, Chicago

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 110 x 280 mm / 17.3 x 4.3 x 11 inch

• Notes

• Sherwood Audio Video Receiver Model RV-4060R.
  Tuning range:
  FM 87,5 - 107,9 Mhz, MW 520-1710kHz
  30 Preset stations
  Tuning Intervals:
  USA/Canada: FM 200kHz, AM 10kHz
  Europe/Australia: FM 50kHz, AM 9kHz
  Power output: 50 watts per channel into 8Ω (stereo)
  Surround output: 35W (front), 35W (center), 35W (rear)
  Frequency response: 30Hz to 40kHz
  Total harmonic distortion: 0.7%
  Damping factor: 40
  Input sensitivity: 180mV (line)
  Signal to noise ratio: 90dB (line)
  Channel separation: 55dB (line)
  Output: 200mV (line)
  Video Connections: composite
  AC Output: 1x Switched max. 100 Watts
  Models:
  USA and Canada - 120VAC 60 Hz - Power Consumption 140 Watts
  Australia and Europe - 230/240VAC
  For other Countries - 110/220VAC (Voltage Selection)

  Accessories: Sherwood RM-RV-46 remote control

• Net weight (2.2 lb = 1 kg)
• 7.5 kg / 16 lb 8.3 oz (16.52 lb)

• Mentioned in
• - - Manufacturers Literature (Operating Instruction)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
