Portable 3-Band Stereo Radio/Cassette Recorder ST-727

Silver (Brand) - Shin-Shirasuna Electric Corp; Nagoya

Data
Forum
Pictures
Collections

  • Year
  • 1982 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 347622
    • alternative name: Shin-Shirasuna Electric Corp. || Shirasuna Denki Mfg. Co. Ltd. || Shirasuna (Shin) Electric Corp.
    • Brand: Plata (brand)

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line plus power jack, mostly with battery or storage battery / 50/60 Hz 110-127; 220-240 / D: 1.5 x 6 / DC: 9 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Portable 3-Band Stereo Radio/Cassette Recorder ST-727 - Silver Brand - Shin-Shirasuna
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 395 x 213 x 113 mm / 15.6 x 8.4 x 4.4 inch
  • Notes

  • Stereo AM/FM/FM-MPX/SW cassette recorder.

    Tuning Range -
    FM: 87.5~108 MHz
    MW: 525~1605 kHz
    SW: 3.9~12 MHz

    Loudspeakers -
    Woofers: 120 mm, 8 ohms x 2
    Tweeters: 22 mm, 8 ohms x 2

    See also Model ST-727L with Long Wave.

  • Net weight (2.2 lb = 1 kg)
  • 4.6 kg / 10 lb 2.1 oz (10.132 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (User manual)
  • Author
  • Model page created by Martin Kent. See "Data change" for further contributors.
