Simon Super Six
Simon Company, Emil J.; New York City
- Country
- United States of America (USA)
- Manufacturer / Brand
- Simon Company, Emil J.; New York City
- Year
- 1923
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 209516
- Number of Tubes
- 6
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 AF stage(s)
- Tuned circuits
- 3 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Simon Super Six - Simon Company, Emil J.; New
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 26.5 x 9.5 x 14 inch / 673 x 241 x 356 mm
- Notes
- E. J. Simon Company Simon Super Six TRF 6-Tube Receiver.
- Price in first year of sale
- 155.00 $
- Author
- Model page created by Alan Larsen. See "Data change" for further contributors.
