Volt-Ohm-Microammeter 269 Series 2 (269-2)

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346036) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346037) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346038) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346039) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346040) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346041) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346042) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346043) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346044) Equipment

Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346045) Equipment
Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346069) Equipment Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346070) Equipment
Use red slider bar for more.
Volt-Ohm-Microammeter 269 Series 2 ; Simpson Electric Co. (ID = 346069) Equipment
Simpson Electric Co.: Volt-Ohm-Microammeter 269 Series 2 [Equipment] ID = 346069 820x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Volt-Ohm-Microammeter 269 Series 2 (269-2), Simpson Electric Co.; Chicago, IL - Lac du Flambeau, WI:
Volt-Ohm-Microammeter with high sensivity 100.000 Ohms/V

Country:  United States of America (USA)
Manufacturer / Brand:  Simpson Electric Co.; Chicago, IL - Lac du Flambeau, WI
Year: 1964 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 1N87G 1N87G
Wave bands - without
Details
Power type and voltage Dry Batteries / 1x 1.5 & 1x 22.5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Volt-Ohm-Microammeter 269 Series 2 - Simpson Electric Co.; Chicago,
Material Bakelite case
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 6 x 7.25 x 3.25 inch / 152 x 184 x 83 mm
Notes

Volt-Ohm-Microammeter (VOM) with 7" meter.

Ranges:

DC Voltage (100,000 ohms per volt): 0 - 1.6, 8, 40, 160, 400, 800, 1600, 4000
AC Voltage (5,000 ohms per volt): 0 - 3, 8, 40, 160, 400, 800
AF Output Voltage (with 0.1 mfd internal series capacitor): 0 - 3, 8, 40, 160
Volume level (calibrated across 600 ohms line): -12 to +11, -3.5 to +19.5, +10.5 to +33.5, +22.5 to 45.5 dB
DC Resistance: 0 - 2000 ohms (12 ohms center); 0 - 20,000 (120 ohms center); 0 - 200,000 ohms (1200 ohms center); 0 - 2 megohms (12,000 ohms center); 0 - 20 megohms (120,000 ohms center); 0 - 200 megohms (1.2 megohms center)
DC Current (215 mV drop maximum): 0 - 16 µA, 0 - 160 µA, 0 - 1.6 mA, 0 - 16 mA, 0 - 160 mA, 0- 1.6 A, 0 - 8 A.

Batteries: one "D" cell, one 22.5 volt battery.

Net weight (2.2 lb = 1 kg) 3.25 lb (3 lb 4 oz) / 1.476 kg
Literature/Schematics (1) - - Manufacturers Literature (User Manual)

Model page created by Víctor Caselli-Diaconescu. See "Data change" for further contributors.



All listed radios etc. from Simpson Electric Co.; Chicago, IL - Lac du Flambeau, WI
Here you find 138 models, 120 with images and 55 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Simpson Electric Co.: Volt-Ohm-Microammeter 269 Series 2
Threads: 1 | Posts: 2
Hits: 1735     Replies: 1
simpson: 269 Series 2 (269-2); Volt-Ohm-Microamme
George Stortz
27.Dec.13
  1 Looking for calibration data for Simpson 269 series 2. Mine reads about 18% low on all voltage ranges. Ω ranges in spec. R37-R-40 have very small effect. Started by adjusting Blue pot (R 39 ) to meter - to read 20.00 K Ω. Thanks, George
George Stortz
19.Jan.14
  2 I found an Army Manual on line which has Calibration details, not much on proceedure, however. This PDF covers several models of Simpson and Triplett VOMs simpson260.com/downloads/tb9-6625-2352-35.pdf
