T.A.C.88

T.A.C.88 ; Sintron Audio; (ID = 1041822) Ampl/Mixer T.A.C.88 ; Sintron Audio; (ID = 1041819) Ampl/Mixer
T.A.C.88 ; Sintron Audio; (ID = 1041825) Ampl/Mixer
Use red slider bar for more.
T.A.C.88 ; Sintron Audio; (ID = 1041822) Ampl/Mixer
Sintron Audio;: T.A.C.88 [Ampl/Mixer] ID = 1041822 933x488
Select picture or schematic to display from thumbnails on the right and click for download.
For model T.A.C.88, Sintron Audio; Iffezheim

Country:  Germany
Manufacturer / Brand:  Sintron Audio; Iffezheim
Year: 1995 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 7: 6SL7GT 6SN7GT 6SN7GT KT88 KT88 KT88 KT88
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker - This model requires external speaker(s).
Power out 2 W (unknown quality)
from Radiomuseum.org Model: T.A.C.88 - Sintron Audio; Iffezheim
Material Metal case, TUBES VISIBLE
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 180 x 270 mm / 16.9 x 7.1 x 10.6 inch
Notes Es gibt eine (spätere?) Umrüstung von 6SL7GT auf ECC83. Ob dies ab Werk war (also eine Variante) ist unklar. Die Tube Amp Company (TAC) ist eine Hausmarke von Sintron.
Net weight (2.2 lb = 1 kg) 19.5 kg / 42 lb 15.2 oz (42.952 lb)

Model page created by Bruno Candreia. See "Data change" for further contributors.



All listed radios etc. from Sintron Audio; Iffezheim
Here you find 15 models, 11 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
