Sprechfunkgerät EL512

Sprechfunkgerät EL512; Sommerkamp (ID = 673984) Commercial TRX

Sprechfunkgerät EL512; Sommerkamp (ID = 673892) Commercial TRX

Sprechfunkgerät EL512; Sommerkamp (ID = 673893) Commercial TRX

Sprechfunkgerät EL512; Sommerkamp (ID = 673896) Commercial TRX

Sprechfunkgerät EL512; Sommerkamp (ID = 673897) Commercial TRX
Sprechfunkgerät EL512; Sommerkamp (ID = 673885) Commercial TRX
Use red slider bar for more.
Sprechfunkgerät EL512; Sommerkamp (ID = 673885) Commercial TRX
Sommerkamp: Sprechfunkgerät EL512 [Commercial TRX] ID = 673885 581x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sprechfunkgerät EL512, Sommerkamp

Country:  Germany
Manufacturer / Brand:  Sommerkamp
alternative name

Sommerkamp El. Schweiz
Year: 1971–1979 Category: Commercial Transmitter & Receiver (TRX not Amateur)
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common)
Wave bands Short Wave (SW only)
Details
Power type and voltage Dry Batteries / 8 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Sprechfunkgerät EL512 - Sommerkamp
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 75 x 190 x 55 mm / 3 x 7.5 x 2.2 inch
Notes Sprechfunkgerät, 2-Kanal AM. FTZ.NR.: K 127/71.
9 Tansistoren: 2SA603 2SA222 2SB56 2SB56 2SB54 2SA322 2SA49 2SA49 2SA222
Literature/Schematics (1) -- Schematic

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
