Inconnu - Unknown 1

Inconnu - Unknown 1 ; Sonneclair, (ID = 701386) Radio
Inconnu - Unknown 1 ; Sonneclair, (ID = 701378) Radio Inconnu - Unknown 1 ; Sonneclair, (ID = 701381) Radio
Inconnu - Unknown 1 ; Sonneclair, (ID = 701379) Radio Inconnu - Unknown 1 ; Sonneclair, (ID = 701382) Radio
Inconnu - Unknown 1 ; Sonneclair, (ID = 701383) Radio Inconnu - Unknown 1 ; Sonneclair, (ID = 701380) Radio
Use red slider bar for more.
Inconnu - Unknown 1 ; Sonneclair, (ID = 701378) Radio
Sonneclair,: Inconnu - Unknown 1 [Radio] ID = 701378 561x647
Select picture or schematic to display from thumbnails on the right and click for download.
For model Inconnu - Unknown 1, Sonneclair, Hannecart & Dannay; Fourmies, Paris, Montreuil, Montrouge

Country:  France
Manufacturer / Brand:  Sonneclair, Hannecart & Dannay; Fourmies, Paris, Montreuil, Montrouge
Year: 1934 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: E447 AK1 E447 E444 E443H 506
Main principle Superheterodyne (common)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: Inconnu - Unknown 1 - Sonneclair, Hannecart & Dannay
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 425 x 510 x 275 mm / 16.7 x 20.1 x 10.8 inch
Notes

Le jeu de lampes n'est pas certain.

Net weight (2.2 lb = 1 kg) 16.6 kg / 36 lb 9 oz (36.564 lb)

Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.
