Junior 604

Junior 604; Sonneclair, (ID = 2322775) Radio Junior 604; Sonneclair, (ID = 2322776) Radio
Junior 604; Sonneclair, (ID = 2322376) Radio
Use red slider bar for more.
Junior 604; Sonneclair, (ID = 2322775) Radio
Sonneclair,: Junior 604 [Radio] ID = 2322775 800x533
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior 604, Sonneclair, Hannecart & Dannay; Fourmies, Paris, Montreuil, Montrouge:
2ememain.be #468373982 seller AUGUSTE

Country:  France
Manufacturer / Brand:  Sonneclair, Hannecart & Dannay; Fourmies, Paris, Montreuil, Montrouge
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Junior 604 - Sonneclair, Hannecart & Dannay
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 155 x 70 mm / 10.6 x 6.1 x 2.8 inch
Notes

6 transistors et 1 diode. 2 gammes d'ondes. Cadre ferrite. Prise antenne-voiture commutable.

Coffret capitonné lavable, havane ou rouge. Housse pour 14 Fr.

Price in first year of sale 195.00 FRF
Mentioned in -- Original prospect or advert (Publicité 1963)
Literature/Schematics (1) Catalogue Comptoir TSF Sud-Est 1963

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
