For model Plein Vent, Sonolor; Paris, La Courneuve

Country:  France
Manufacturer / Brand:  Sonolor; Paris, La Courneuve
Year: 1971 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7:
Main principle Superheterodyne (common); ZF/IF 480 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Plein Vent - Sonolor; Paris, La Courneuve
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 290 x 190 x 85 mm / 11.4 x 7.5 x 3.3 inch
Notes

6 gammes d'ondes:

  • GO (LW), PO (MW)
  • BE1 (SW1) de 3.1 à 5.1 MHz
  • BE2 (SW2) de 4.7 à 7.4 MHz
  • OC3 (SW3) de 7.0 à 15.5 MHz
  • OC4 (SW4) de 14.5 à 26.5 MHz

7 transistors + diodes. Clavier 8 touches dont commutateur antenne auto et éclairage. Cadre ferroxcube, antenne télescopique pour OC. Réglage de tonalité. HP elliptique de 12 x 19 cm.

Coffret matière plastique gainé simili-cuir.

Même modèle avec 4 stations préréglées voir Plein Jour.

Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Mentioned in -- Original prospect or advert

Model page created by Jean-Louis Buton. See "Data change" for further contributors.
