Globe Navigator TSG-R
Use red slider bar for more.
Sonora Radio & Telev: Globe Navigator TSG-R [Radio] ID = 183365 417x580
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Sonora Electric Phono | ||||
|---|---|---|---|---|---|
| Year: 1940 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: 12A8GT 12K7GT 12Q7GT 35L6GT 35Z5GT |
| Main principle | Superheterodyne (common); ZF/IF 456 kHz |
|---|---|
| Tuned circuits | 5 AM circuit(s) |
| Wave bands | Broadcast only (MW). |
| Details | |
| Power type and voltage | AC/DC-set / 117 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm |
| Power out | |
| from Radiomuseum.org | Model: Globe Navigator TSG-R - Sonora Radio & Telev. Corp.; |
| Material | Various materials |
| Shape | Design Radio or Novelty / Gadget - fancy or unusual shape. |
| Notes | Just Turn the World to Tune, Watch History Being Made, Built-in Sonorascope Aerial, includes the 1712kHz police Channel, 10" Globe. |
| Price in first year of sale | 29.00 $ |
| External source of data | Ernst Erb |
| Circuit diagram reference | Rider's Perpetual, Volume 12 = ca. 1941 and before |
