Radio-Phono Élégance IV (4)

Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2103083) Radio
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023589) Radio Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023590) Radio
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023259) Radio Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023593) Radio
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023594) Radio Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023596) Radio
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023591) Radio Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023597) Radio
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2068895) Radio
Use red slider bar for more.
Radio-Phono Élégance IV ; Sonora-Radio; Paris, (ID = 2023589) Radio
Sonora-Radio; Paris,: Radio-Phono Élégance IV [Radio] ID = 2023589 1400x1477
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio-Phono Élégance IV (4), Sonora-Radio; Paris, Puteaux:
Frontansicht mit geöffnetem Deckel

Country:  France
Manufacturer / Brand:  Sonora-Radio; Paris, Puteaux
Year: 1952 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6BE6 6BA6 6AT6 6AQ5 6AF7 6X4
Main principle Superheterodyne (common); ZF/IF 478 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Radio-Phono Élégance IV - Sonora-Radio; Paris, Puteaux
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 380 x 360 mm / 21.7 x 15 x 14.2 inch
Notes

Radio-phono equipé avec le châssis Élégance IV.

4 gammes d'ondes dont OC de 16 à 50 m et BE (bande étalée) de 44 à 50 m.

Tourne-disque 78 tours avec pick-up à aiguilles.


Radio mit oben eingebautem Plattenspieler für Schellackplatten (78 Upm), Abtastsystem mit auswechselbarer Grammophon-Stahlnadel. Bereich KW 1 ist von 16 bis 50 Meter, KW 2 ist gespreizt von 44 bis 50 Meter.

Verspiegelte Skala.

Net weight (2.2 lb = 1 kg) 16.2 kg / 35 lb 10.9 oz (35.683 lb)

Model page created by Stefan Hammermayer. See "Data change" for further contributors.
