For model 4 Band Receiver ICF-880L, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1991 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present. TA7358 CXA1019S
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / AC 220; Batt. 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.43 W (unknown quality)
from Radiomuseum.org Model: 4 Band Receiver ICF-880L - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 255 x 129 x 62 mm / 10 x 5.1 x 2.4 inch
Notes 4 Band Receiver mit Tragegriff, FM-3 Fixstationen, Drehko-Abstimmung über Zahnriemen, Teleskop 60 cm, Ferritantenne 12 cm, Kopfhöreranschluß über 3,5 mm Klinkenbuchse
Net weight (2.2 lb = 1 kg) 1.250 kg / 2 lb 12.1 oz (2.753 lb)
Source of data - - Data from my own collection
Mentioned in - - Manufacturers Literature (Service-Manual)

Model page created by Guido Höh. See "Data change" for further contributors.
