Cassette-Corder TCM-450DV

Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233715) R-Player Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233716) R-Player
Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233717) R-Player Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233718) R-Player
Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233719) R-Player Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233721) R-Player
Use red slider bar for more.
Cassette-Corder TCM-450DV; Sony Corporation; (ID = 1233715) R-Player
Sony Corporation;: Cassette-Corder TCM-450DV [R-Player] ID = 1233715 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cassette-Corder TCM-450DV, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 2004 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Batteries / addl. power jack / 2 x 1,5 / 3 Volt
Loudspeaker -Loudspeaker incorporated, but system not known. / Ø 3.6 cm = 1.4 inch
Power out 0.45 W (unknown quality)
from Radiomuseum.org Model: Cassette-Corder TCM-450DV - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 80 x 110 x 29 mm / 3.1 x 4.3 x 1.1 inch
Notes Tape speed 4,8 cm/s or 2,4 cm/s; frequency range 250-6300 Hz using normal cassette; variable range of the tape speed: from +30% to -20%. Two diodes operation indicators. Voice Operated Recording (VOR): on/off. Flat built-in condenser microphone, pause key, tape counter, cue and review. Earphone jack ( minijack) for 8-300 ohms earphone; jack for power adaptor, not supplied. Socket also for external microphone.
Full aluminium body. AAA batteries. Carring pouch.
Net weight (2.2 lb = 1 kg) 0.170 kg / 0 lb 6 oz (0.374 lb)
Mentioned in - - Manufacturers Literature (Sony operating instructions)

Model page created by Felice Nicolini. See "Data change" for further contributors.
