• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 2005

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 243213

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 450/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• CD-Player, -Writer, MD, MOD (audio)

• Power type and voltage
• Line / Batteries (any type) / 230 / 6 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 3.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: CD Radio Cassette-Corder CFD-S03CPL - Sony Corporation; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 360 x 141 x 235 mm / 14.2 x 5.6 x 9.3 inch

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
