Compact Disc Player CDP-295

Sony Corporation; Tokyo

  • Year
  • 1990/1991
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 126729

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 120; 220; 240; 220-230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player CDP-295 - Sony Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 100 x 280 mm / 16.9 x 3.9 x 11 inch
  • Notes
  • A stereo hi-fi compact disc player with remote control (RM-D295). High Density Linear Converter. With Shuffle Play, Program Play, Program Edit. Time Edit, Repeat Play, Music Scan and Fading In and Out. RCA phono sockets for Line Out, jack for headphones with volume control.

    Specification
    Frequency response 2 Hz - 20 kHz ± 0.5dB
    Signal to noise ratio More than 100 dB
    Dynamic range More than 97 dB
    Harmonic distortion Less than 0.005%
    Channel separation More than 95 dB
    Line Out
    (phono jacks)
    Output level 2 V (at 50 kΩ)
    Load impedance over 10 kΩ
    Headphones
    (stereo phone jack)
    Output level max 10 mW
    Load impedance 32 Ω

    Versions/Power Requirements
    Canada Model  /  120V AC 60Hz
    AEP Model  /  220-230V AC 50/60Hz
    E model  /  110, 120, 220 or 240V AC 50/60Hz adjustable
    Australian model  /  240V AC 50Hz

    Power consumption     12W

    Similar to the Sony CDP-491 (US & UK models) Compact Disc Player and to the Sony CDP-195 Compact Disc Player which has no remote control.

    Dazugehörige Fernbedienung: RM-D295, auch verwendbar: RM-D350 (mit der Einschränkung: keine CD-Index-Anwahl). 1bit-D/A-Konverter mit 256-fachem Oversampling.

    Made in France.

  • Net weight (2.2 lb = 1 kg)
  • 3.5 kg / 7 lb 11.3 oz (7.709 lb)
  • Price in first year of sale
  • 248.00 DM
  • Source of data
  • - - Data from my own collection
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual CDP-195/295/491 dated 1991.3)
  • Author
  • Model page created by Klemens Rhode. See "Data change" for further contributors.
