For model CF-950S, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1976–1980 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 45:
Main principle Superhet, double/triple conversion; ZF/IF 10700/455 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 120; 220; 240 / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: CF-950S - Sony Corporation; Tokyo
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 430 x 300 x 150 mm / 16.9 x 11.8 x 5.9 inch
Notes SW 1600 - 22100 kHz in three ranges, AM/SSB (BFO), Wadley-loop, crystal calibrator 250 kHz. 13 ICs und 29 Transistoren im Rundfunkteil.
Net weight (2.2 lb = 1 kg) 5.6 kg / 12 lb 5.4 oz (12.335 lb)
Price in first year of sale 548.00 DM
External source of data R. Lichte

Model page created by Martin Bösch. See "Data change" for further contributors.
