Compact-Disc-Player CDP-397

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455580) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455581) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455582) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455583) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455584) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455585) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455586) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455587) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455588) R-Player

Compact-Disc-Player CDP-397; Sony Corporation; (ID = 2455589) R-Player
Compact-Disc-Player CDP-397; Sony Corporation; (ID = 1885858) R-Player Compact-Disc-Player CDP-397; Sony Corporation; (ID = 1885859) R-Player
Use red slider bar for more.
Compact-Disc-Player CDP-397; Sony Corporation; (ID = 1885858) R-Player
Sony Corporation;: Compact-Disc-Player CDP-397 [R-Player] ID = 1885858 900x337
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact-Disc-Player CDP-397, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1992 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio)
Power type and voltage Alternating Current supply (AC) / 220 - 230 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact-Disc-Player CDP-397 - Sony Corporation; Tokyo
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 100 x 295 mm / 16.9 x 3.9 x 11.6 inch
Notes

Anschlüsse

  • Anzahl der Ausgänge: 2
    • 2 x RCA Line-Out
    • 1 x Kopfhörer 6,3 mm Klinke

Technische Daten

  • Wandler:
  • Frequenzgang: 2Hz - 20kHz (+/- 0,5 dB)
  • Dynamikbereich: über 96 dB
  • Signalrauschabstand: über 100 dB
  • Klirrfaktor: unter 0,0045%
  • Kanaltrennung: über 95 dB
  • CD-Text: nein
  • MP3-Unterstützung: nein
  • Pitch-Kontrolle: nein
  • Anspielautomatik: ja
  • Shuffle: ja
  • Titel-Programmierung: ja
  • Repeat: ja
  • Spielt CD-R/CD-RW/HDCD: CD-R


Besondere Ausstattungen

  • Separate Lautstärkeregelung für Kopfhörer
  • Automatische Programmierung unter Vorgabe der Spielzeit
  • Fader zum Ausblenden eines Titels
  • Time Fade (Ausblendung zu einer programmierten Zeit)
  • Peak Search (Automatisches Aufsuchen eines Spitzenpegels auf der CD)
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Price in first year of sale 349.00 DM

Model page created by Holger Struthoff. See "Data change" for further contributors.
