Compact Disc Player CDP-X505ES

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1993/1994
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 316528

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 120; 220; 240; 220-230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player CDP-X505ES - Sony Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 470 x 125 x 375 mm / 18.5 x 4.9 x 14.8 inch
  • Notes

  • A stereo hi-fi compact disc player housed in a metal case in black (with remote control RM-D991) or gold (with remote control RM-D891) with wooden side panels (except the Australian  model - see note below). High Density Linear Converter, Direct Digital Sync. With Continuous play, Auto-Cue, Shuffle play, Program play, Music Scan, Repeat play, Fade-in/Fade out, Custom Edit, Multi-disc program, Time Edit/Just Edit, Peak Search, Custom Files (Disc memo, Custom Index, Program Bank, Delete Bank, Level file), Timer Activated playing. With RCA phono sockets for Fixed and Variable Line Out, a digital optical output connector and a jack for headphones with volume control.

    Specification
    Laser ( KSS-272A) Semiconductor laser
    Wavelength 780-790nm
    Frequency response 2 Hz - 20 kHz ±0.3 dB
    Signal to noise ratio More than 118 dB
    Dynamic range More than 100 dB
    Harmonic distortion Less than 0.0017%
    Channel separation More than 110 dB
    Outputs
    LINE OUT (FIXED) Output level 2V (at 50 kΩ)
    Load impedance over 10 kΩ
    LINE OUT (VARIABLE) Output level max. 2V (at 50 kΩ)
    Load impedance over 50 kΩ
    DIGITAL OUT (OPTICAL) Wave length 660 nm
    Output level -18 dBm
    HEADPHONES
    (Stereo phone jack)    		 Output level max 28 mW
    Load impedance 32 Ω

    Versions/power requirements
    AEP model /  220-230V AC 50/60Hz
    Australian model /  240V AC 50Hz
    E, Saudi Arabia model /  110, 120, 220 or 240V AC 50/60Hz adjustable

    Power consumption:  29W

    The Australian model cabinet variation
    The Australian model does not have wooden side panels so its dimensions differ.
    Dimensions (WHD) :   430 x 125 x 375 mm (17 x 5 x 14⅞ inches)

    Weight variations
    European model: 13.2 kg (29 lbs 2 oz)
    Australian model: 12.5 kg (27 lbs 9 oz)
    Other country models: 12.3 kg (27 lbs 2 oz)

  • Net weight (2.2 lb = 1 kg)
  • 13.2 kg / 29 lb 1.2 oz (29.075 lb)
  • Mentioned in
  • -- Original prospect or advert (Sony General catalogue '94)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual CDP-X505ES dated 1993.4)
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Operating Instructions CDP-X505ES/CDP-X303ES/X202ES dated 1993)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
