Cube clock radio ICF-A7

Sony Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Sony Corporation; Tokyo

Year
1989 ??

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
121161

Schematics

Cube clock radio ICF-A7; Sony Corporation; (ID = 818286) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818287) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818288) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818289) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818290) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818291) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 818292) Radio — Sony Corporation; Cube clock radio ICF-A7 (3)

Cube clock radio ICF-A7; Sony Corporation; (ID = 386019) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008339) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008340) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008341) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008342) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008343) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008344) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008345) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Cube clock radio ICF-A7; Sony Corporation; (ID = 2008346) Radio — Sony Corporation; Cube clock radio ICF-A7 (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
3

Semiconductors

Main principle
ZF/IF 455/10700 kHz

Wave bands
Broadcast (BC) and FM or UHF.

Power type and voltage
Dry Batteries / 2 × 1,5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 cm = 1.6 inch

Power out
0.1 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Cube clock radio ICF-A7 - Sony Corporation; Tokyo

Shape
Tablemodel with Clock ((Alarm-) Clock Radio).

Dimensions (WHD)
91 x 95 x 87 mm / 3.6 x 3.7 x 3.4 inch

Notes
Battie clock: 1,5 Volt; Ext. power jack: DC 3 Volt.

Net weight (2.2 lb = 1 kg)
0.390 kg / 0 lb 13.7 oz (0.859 lb)

Source of data
-- Original-techn. papers.

Author
Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
