• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 162814

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 20

• Semiconductors

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)     2 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 120 / 8 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 4 inch = 10.2 cm

• Power out
• 4.7 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Earth Orbiter CRF-5100 [E] - Sony Corporation; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 13.5 x 9 x 6.5 inch / 343 x 229 x 165 mm

• Notes
• Also includes AIR band 108-136 MHz and PSB band 147-174 MHz.

• Net weight (2.2 lb = 1 kg)
• 14.2 lb (14 lb 3.2 oz) / 6.447 kg

• Price in first year of sale
• 175.00 $

• Source of data
• - - Manufacturers Literature
