FM/AM Walkman SRF-M32

FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2322728) Radio
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291292) Radio FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291293) Radio
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291294) Radio FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291295) Radio
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291296) Radio FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291297) Radio
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291298) Radio FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291299) Radio
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291300) Radio FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291301) Radio
Use red slider bar for more.
FM/AM Walkman SRF-M32; Sony Corporation; (ID = 2291292) Radio
Sony Corporation;: FM/AM Walkman SRF-M32 [Radio] ID = 2291292 1400x1258
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM/AM Walkman SRF-M32, Sony Corporation; Tokyo:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1995/1996 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop; ZF/IF 450/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / AAA: 2 × 1,5 Volt
Loudspeaker - For headphones or amp.
Power out 0.036 W (unknown quality)
from Radiomuseum.org Model: FM/AM Walkman SRF-M32 - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 81 x 72 x 27.5 mm / 3.2 x 2.8 x 1.1 inch
Notes

2 × 5 Presets. Time display. Supplied with stereo headphones and belt holder.

Net weight (2.2 lb = 1 kg) 0.082 kg / 0 lb 2.9 oz (0.181 lb)
Mentioned in - - Manufacturers Literature (SRF-M32 Service Manual dated 1998)
Literature/Schematics (4) Owners manual. 1995.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
