FM/SW/MW 3 Band Radio ICF-790 S

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1998
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 229618

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 220-230 / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 0.43 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM/SW/MW 3 Band Radio ICF-790 S - Sony Corporation; Tokyo
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 258 x 133 x 65 mm / 10.2 x 5.2 x 2.6 inch
  • Notes

  • FM 87,6-107,5 MHz, MW 531-1602 kHz, SW 5,95-18 MHz.

    Gehäusefarben: schwarz oder weiss (elfenbein)

  • Net weight (2.2 lb = 1 kg)
  • 0.975 kg / 2 lb 2.4 oz (2.148 lb)
  • Author
  • Model page created by Jörg Holtzapfel. See "Data change" for further contributors.
