• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1999 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 339212

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 111

• Semiconductors

• Wave bands
• - without

• Details
• Special Tape or Cassette-Format

• Power type and voltage
• Batteries / addl. power jack / 7,2; 8,4 Volt

• Loudspeaker
• - only for Earphone!

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Handycam video Hi8 XR CCD-TR950E PAL - Sony Corporation; Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 102 x 106 x 195 mm / 4 x 4.2 x 7.7 inch

• Notes

• This camcorder has two helical scanning rotary heads for video and FM sound.
  Video signal is PAL colour, CCIR standard, using 8 mm video format cassette Hi8 or Standard 8.

  • Focal distance: 3.6 ÷72 mm. When converted to a 35 mm still camera: 41 - 820 mm.
  • S video output: 4 Pin mini-DIN, Luminance signal: 1 V p-p, 75 Ω unbalanced. Chrominance signal: 0.3 V p-p, 75 Ω unbalanced.
  • Video output: Phono jack,1 V p-p 75 Ω unbalanced.
  • Audio output: Phono jack stereo, 327 mV impedance less than 2.2 kΩ.
  • Headphone jack: Stereo minijack Ø 3.5 mm.
  • Mic jack: Minijack, 0.388 mV low impedance with 2.5 to 3 V DC output stereo.
  • Power requirement: Internal battery pack 7.2 V. AC power adaptor 50/60 Hz 100 - 240 V with output  DC 8.4 V.

  111 Transistors, 31 ICs, and 44 Diodes.

• Net weight (2.2 lb = 1 kg)
• 0.810 kg / 1 lb 12.5 oz (1.784 lb)

• Mentioned in
• Original Service Manual from Manualslib.com.

• Author
• Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
