PLL Synthesized Receiver ICF-2010

Sony Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Sony Corporation; Tokyo

Year
1985

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
75236

Schematics

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2029452) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (3)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2029454) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (3)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2029455) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (3)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2029456) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (3)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2029457) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (3)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2614128) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (1)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 1215382) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
Ebay Seller tj48025r89 Item 270955143180

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 1215383) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
Ebay Seller tj48025r89 Item 270955143180

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 471125) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (1)

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 1215379) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
Ebay Seller tj48025r89 Item 270955143180

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 1215381) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
Ebay Seller tj48025r89 Item 270955143180

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 1215384) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
Ebay Seller tj48025r89 Item 270955143180

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841610) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841611) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841612) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841613) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841614) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

PLL Synthesized Receiver ICF-2010; Sony Corporation; (ID = 2841616) Radio — Sony Corporation; PLL Synthesized Receiver ICF-2010 (2)
eBay item number:195458922063

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
PLL, Phase-locked loop; ZF/IF 19055/455 kHz

Wave bands
Broadcast, Long Wave, Short Wave plus FM or UHF.

Power type and voltage
Dry Batteries / 4,5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: PLL Synthesized Receiver ICF-2010 - Sony Corporation; Tokyo

Shape
Portable set > 8 inch (also usable without mains)

Dimensions (WHD)
290 x 160 x 55 mm / 11.4 x 6.3 x 2.2 inch

Notes
Coverage 150 - 30000 kHz, additional AIR band 116 - 136 MHz; AM, SSB (USB, LSB, ECSS-Sync), digital frequency readout, frequency keypad entry, 32 memories, clock. US model, sold elsewhere as Sony ICF-2001D

Net weight (2.2 lb = 1 kg)
2.3 kg / 5 lb 1.1 oz (5.066 lb)

Author
Model page created by Martin Bösch. See "Data change" for further contributors.
