ICF-5900W

ICF-5900W; Sony Corporation; (ID = 117152) Radio

ICF-5900W; Sony Corporation; (ID = 117153) Radio

ICF-5900W; Sony Corporation; (ID = 556104) Radio

ICF-5900W; Sony Corporation; (ID = 556129) Radio

ICF-5900W; Sony Corporation; (ID = 556166) Radio

ICF-5900W; Sony Corporation; (ID = 556196) Radio

ICF-5900W; Sony Corporation; (ID = 556200) Radio

ICF-5900W; Sony Corporation; (ID = 556218) Radio

ICF-5900W; Sony Corporation; (ID = 556264) Radio

ICF-5900W; Sony Corporation; (ID = 556266) Radio
ICF-5900W; Sony Corporation; (ID = 274641) Radio ICF-5900W; Sony Corporation; (ID = 94113) Radio
ICF-5900W; Sony Corporation; (ID = 121823) Radio ICF-5900W; Sony Corporation; (ID = 121824) Radio
ICF-5900W; Sony Corporation; (ID = 121825) Radio ICF-5900W; Sony Corporation; (ID = 121826) Radio
ICF-5900W; Sony Corporation; (ID = 198096) Radio ICF-5900W; Sony Corporation; (ID = 198097) Radio
ICF-5900W; Sony Corporation; (ID = 198098) Radio ICF-5900W; Sony Corporation; (ID = 274640) Radio
Use red slider bar for more.
ICF-5900W; Sony Corporation; (ID = 274641) Radio
Sony Corporation;: ICF-5900W [Radio] ID = 274641 682x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model ICF-5900W, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 10700/455 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage Dry Batteries
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1.9 W (unknown quality)
from Radiomuseum.org Model: ICF-5900W - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable also without mains)
Dimensions (WHD) 220 x 230 x 100 mm / 8.7 x 9.1 x 3.9 inch
Notes Sony ICF-5900W;
Coverage vhf-fm, mw, sw in three bands:
3.9 - 10.0 MHz,
11.7 - 20.0 MHz,
& 20.0 - 28.0 MHz,
am, ssb (bfo), crystal calibrator 250 kHz; wadley loop.
Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Price in first year of sale 398.00 DM
Collectors' prices
External source of data R.Lichte
Mentioned in -- Original-techn. papers.

Model page created by Martin Bösch. See "Data change" for further contributors.



All listed radios etc. from Sony Corporation; Tokyo
Here you find 3062 models, 2786 with images and 640 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Sony Corporation;: ICF-5900W
Threads: 1 | Posts: 2
Hits: 1964     Replies: 1
sony: ICF-5900W: Shared 10.7MHz IF
Michael Watterson
02.May.12
  1

On Shortwave (HF) this is a "dual conversion" receiver. The first 10.7MHz IF amp and two 10.7MHz ceramic filters are used on VHF-FM and also HF. The second 10.7MHz IF amp is a mixer (presumably fed by fixed 10.24MHz approx)  on SW down to the 455KHz IF. On MW (BC) it appears to be single conversion.
