ICF-703L

ICF-703L; Sony Corporation; (ID = 1072603) Radio
ICF-703L; Sony Corporation; (ID = 1239920) Radio ICF-703L; Sony Corporation; (ID = 1072602) Radio
ICF-703L; Sony Corporation; (ID = 2268566) Radio ICF-703L; Sony Corporation; (ID = 2268570) Radio
ICF-703L; Sony Corporation; (ID = 2268567) Radio ICF-703L; Sony Corporation; (ID = 1688964) Radio
ICF-703L; Sony Corporation; (ID = 1688966) Radio ICF-703L; Sony Corporation; (ID = 1688967) Radio
ICF-703L; Sony Corporation; (ID = 1688968) Radio ICF-703L; Sony Corporation; (ID = 1688969) Radio
Use red slider bar for more.
ICF-703L; Sony Corporation; (ID = 1239920) Radio
Sony Corporation;: ICF-703L [Radio] ID = 1239920 933x609
Select picture or schematic to display from thumbnails on the right and click for download.
For model ICF-703L, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 2000 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present. CXA1019S
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 220-230 / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.2 cm = 4 inch
Power out 0.43 W (unknown quality)
from Radiomuseum.org Model: ICF-703L - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 137 x 69 mm / 10.4 x 5.4 x 2.7 inch
Notes Frequency range:
Band ICF-703L ICF-703
FM 87.5 - 108 MHz 87.5 - 108 MHz
AM (MW) 530 - 1605 kHz 530 - 1605 kHz
LW 153 - 255 kHz --





There is no seperate service manual for this model.
Please use combined service manual for
ICF-703
Net weight (2.2 lb = 1 kg) 1.019 kg / 2 lb 3.9 oz (2.244 lb)
