FM/AM-Radio ICF-8
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1998
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 283845
Internal view of PCB upperside
PCB lower side
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / AA: 2 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.7 cm = 2.2 inch
- Power out
- 0.1 W (undistorted)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: FM/AM-Radio ICF-8 - Sony Corporation; Tokyo
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 133 x 72 x 33.5 mm / 5.2 x 2.8 x 1.3 inch
- Notes
-
Antenna esterna, uscita per cuffia, controllo volume, commutatore AM/FM.
- Net weight (2.2 lb = 1 kg)
- 0.206 kg / 0 lb 7.3 oz (0.454 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
- Other Models
-
Here you find 3913 models, 3773 with images and 947 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sony Corporation; Tokyo
Collections
The model FM/AM-Radio is part of the collections of the following members.
Forum contributions about this model: Sony Corporation;: FM/AM-Radio ICF-8
Threads: 1 | Posts: 1
Dieses Gerät hat ein erstaunliches Detail : Im Gegensatz zu den meisten anderen Radiogeräten ist der " Ein - Aus - Schalter " nicht mit dem Lautstärke - Regler kombiniert, sondern mit dem Wellenschalter.
Ottmar Lauth, 18.Jul.18
