ICF-SW100 E

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1996
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 293072

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 2 × 1,5 / 3 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: ICF-SW100 E - Sony Corporation; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 111 x 24 x 75 mm / 4.4 x 0.9 x 3 inch
  • Notes

  • Radio with digital tuner,FM, MW, LW, SW 13, FM stereo, 50 presets, SSB (Single Side Band), steps from 1 kHz in AM, synchronized detection, time-name indication of the city X 24, multi-information LCD display, clock and programmable timer, direct access to frequencies, automatic search, costumized edition of the received station, compact antenna, headphones out.

  • Net weight (2.2 lb = 1 kg)
  • 0.220 kg / 0 lb 7.8 oz (0.485 lb)
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
