ICF-S11W

• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1984

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 94133

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• CX20075 or. CX20091 DTC144 1S953 1S953 TLUR122

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / 2 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.6 cm = 1.4 inch

• Power out
• 0.07 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: ICF-S11W - Sony Corporation; Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 92 x 56 x 13 mm / 3.6 x 2.2 x 0.5 inch

• Notes

• This compact pocket ICF-S11W model features MW (530-1605KHz) and FM (87.6-108MHz or 87.6-107MHz depending on region).

  It uses a single IC, a transistor, and a couple of diodes.The IC have at least two variants, one being the CX20075 referred in the service manual, and another being the CX20091 as seen in my unit.

  There is a model variant ICF-S11 with same features but features a FM band from 76-108MHz instead.



• Net weight (2.2 lb = 1 kg)
• 0.1 kg / 0 lb 3.5 oz (0.22 lb)
