• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1988 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 211053

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 180 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Integrated Stereo Amplifier TA-F500ES - Sony Corporation; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 148 x 373 mm / 16.9 x 5.8 x 14.7 inch

• Notes
• Integrated Stereo Amplifier, 2x 90 watts RMS into 8 ohms, THD 0,006%, 2 - 200.000Hz.
  Comes with a Spontaneous Twin Drive System, Dual Input Selectors, two sets of Speaker Outputs, a set of Adapter Inputs & Outputs for connecting an Optional Stereo Graphic Equalizer or Preamp.
  Audio Inputs for connecting a Tuner, Compact Disc Player, a Tape Player / Recorder, Phono, Video One, Video Two, a Video Monitor Output, and an additonal Auxilary Input.
  There are Tone Control for the Bass, Treble, Balance, and Master Attenuator Volume Control. Also, this comes with a CD Source Direct, MM / MC Phono Cartridge Selector, Audio Record Output Selector, a Tone Control, High / Low Subsonic Filter, two sets of Automatic Shut Off Switched AC Outlets, two sets of Constant Power Unswitched AC Power Outlets, and a Headphone Monitor Jack.
  Part of Sony's ESPRIT-Series.

• Net weight (2.2 lb = 1 kg)
• 13.2 kg / 29 lb 1.2 oz (29.075 lb)

• Source of data
• -- Original prospect or advert

• Mentioned in
• Prospekt "Sony'88 - HiFi - It's a Sony" Seiten 14 und 36

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
