Micro HiFi Component System HCD-HPX7
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 2001 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 292296
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- PLL, Phase-locked loop; ZF/IF 450/10700 kHz
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Details
- Other Combination - see Notes; Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 120 W (200 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Micro HiFi Component System HCD-HPX7 - Sony Corporation; Tokyo
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
-
- Micro Hifi Component System
- Player CD, CD-R, CD-RW and MP3
- Player CD 5 disc
- Imput AUX
- Dynamic Sound Generator
- Output Phones.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- Author
- Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
