Radio Cassette-Corder CFS-828S E15, UAE Model

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 2001
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 279062

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 50/60Hz, 110-120/220-240; 6 x 1,5 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 9 W (max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Radio Cassette-Corder CFS-828S [E15, UAE Model] - Sony Corporation; Tokyo
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 679 x 263.5 x 239.5 mm / 26.7 x 10.4 x 9.4 inch
  • Notes

  • Sony Portable Sound System Model CFS-828S.
    Max. Power Output 9 Watts
    Frequency Range:
    FM 87,5 - 108 MHz
    MW 530 - 1605 kHz
    SW1 2,3 - 7 MHz
    SW2 7 - 22 MHz
    Double Cassette Player/Recorder
    4-track, 2-channel stereo, 80 - 12500Hz
    Tape Transport Mechanism Type: MF-W828-117
    Detachable 2-Way Speaker System:
    1x FullRange 10cm Cone Type, 6 Ohms
    1x Tweeter 2cm
    Power Consumption AC 18 Watts

    Suffix:
    E15:  220-240VAC area in E-Model
    EA: Saudi Arabia Model
    UAE: United Arab Emirates Model



  • Net weight (2.2 lb = 1 kg)
  • 7.3 kg / 16 lb 1.3 oz (16.079 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
