Shower Mate ICF-S77L

Shower Mate ICF-S77L; Sony Corporation; (ID = 686296) Radio Shower Mate ICF-S77L; Sony Corporation; (ID = 686286) Radio
Shower Mate ICF-S77L; Sony Corporation; (ID = 686289) Radio Shower Mate ICF-S77L; Sony Corporation; (ID = 686290) Radio
Shower Mate ICF-S77L; Sony Corporation; (ID = 686293) Radio Shower Mate ICF-S77L; Sony Corporation; (ID = 686294) Radio
Shower Mate ICF-S77L; Sony Corporation; (ID = 686295) Radio Shower Mate ICF-S77L; Sony Corporation; (ID = 1002782) Radio
Shower Mate ICF-S77L; Sony Corporation; (ID = 1002783) Radio Shower Mate ICF-S77L; Sony Corporation; (ID = 1002784) Radio
Use red slider bar for more.
Shower Mate ICF-S77L; Sony Corporation; (ID = 686296) Radio
Sony Corporation;: Shower Mate ICF-S77L [Radio] ID = 686296 933x539
Select picture or schematic to display from thumbnails on the right and click for download.
For model Shower Mate ICF-S77L, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1997 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 1:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Shower Mate ICF-S77L - Sony Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 225 x 130 x 43 mm / 8.9 x 5.1 x 1.7 inch
Notes Spritzwassergeschützter 3-Band Radio mit Digital Quartz Clock (Timer 15 - 60 Minuten),- wahlweise mit Aufstellbügel oder Wandmontage, Spannungsversorgung für Radio: 3 x 1,5 Volt, für Clock-Betrieb 1 x 1,5 Volt, Wurfantenne für UKW, Ferritantenne für AM 12 cm, 2 integrierte Schaltkreise: CXA1019M und TC9160P
Net weight (2.2 lb = 1 kg) 0.570 kg / 1 lb 4.1 oz (1.256 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
